Choose a version:

InlineStack

Use this to organize layout elements along the horizontal axis of the page. It's great for horizontal alignment.

Anchor to inlinestackpropsInlineStackProps

Anchor to accessibilityLabel accessibilityLabel string: A label that describes the purpose or contents of the element. When set, it will be announced to users using assistive technologies and will provide them with more context. When set, any children or label supplied will not be announced to screen readers.
Anchor to accessibilityRole accessibilityRole Default: 'generic': Sets the semantic meaning of the component’s content. When set, the role will be used by assistive technologies to help users navigate the page.
Anchor to blockAlignment blockAlignment Default: 'start': Position children along the cross axis
Anchor to blockGap blockGap | boolean: Adjust spacing between elements in the block axis.

Alias for rowGap
Anchor to blockSize blockSize number | `${number}%`: Adjust the block size.

number: size in pixels.

`${number}%`: size in percentages of the available space.
Anchor to columnGap columnGap | boolean: Adjust spacing between children in the inline axis
Anchor to gap gap < | boolean>: Adjust spacing between children
Anchor to id id string: A unique identifier for the element.
Anchor to inlineAlignment inlineAlignment Default: 'start': Position children along the main axis
Anchor to inlineGap inlineGap | boolean: Adjust spacing between elements in the inline axis.

Alias for columnGap
Anchor to inlineSize inlineSize number | `${number}%`: Adjust the inline size.

number: size in pixels.

`${number}%`: size in percentages of the available space.
Anchor to maxBlockSize maxBlockSize number | `${number}%`: Adjust the maximum block size.

number: size in pixels.

`${number}%`: size in percentages of the available space.
Anchor to maxInlineSize maxInlineSize number | `${number}%`: Adjust the maximum inline size.

number: size in pixels.

`${number}%`: size in percentages of the available space.
Anchor to minBlockSize minBlockSize number | `${number}%`: Adjust the minimum block size.

number: size in pixels.

`${number}%`: size in percentages of the available space.
Anchor to minInlineSize minInlineSize number | `${number}%`: Adjust the minimum inline size.

number: size in pixels.

`${number}%`: size in percentages of the available space.
Anchor to padding padding < | boolean>: Adjust the padding.

To shorten the code, it is possible to specify all the padding for all edges of the box in one property.

base means block-start, inline-end, block-end and inline-start paddings are base.

base none means block-start and block-end paddings are base, inline-start and inline-end paddings are none.

base none large means block-start padding is base, inline-end padding is none, block-end padding is large and inline-start padding is none.

base none large small means block-start padding is base, inline-end padding is none, block-end padding is large and inline-start padding is small.

true applies a default padding that is appropriate for the component.

Learn more about the 1-to-4-value syntax at https://developer.mozilla.org/en-US/docs/Web/CSS/Shorthand_properties#edges_of_a_box
Anchor to paddingBlock paddingBlock < | boolean>: Adjust the block-padding.

base none means block-start padding is base, block-end padding is none.
Anchor to paddingBlockEnd paddingBlockEnd | boolean: Adjust the block-end padding.
Anchor to paddingBlockStart paddingBlockStart | boolean: Adjust the block-start padding.
Anchor to paddingInline paddingInline < | boolean>: Adjust the inline padding.

base none means inline-start padding is base, inline-end padding is none.
Anchor to paddingInlineEnd paddingInlineEnd | boolean: Adjust the inline-end padding.
Anchor to paddingInlineStart paddingInlineStart | boolean: Adjust the inline-start padding.
Anchor to rowGap rowGap | boolean: Adjust spacing between children in the block axis

AccessibilityRole

'main' | 'header' | 'footer' | 'section' | 'aside' | 'navigation' | 'ordered-list' | 'list-item' | 'list-item-separator' | 'unordered-list' | 'separator' | 'status' | 'alert' | 'generic'

CrossAxisAlignment

'start' | 'center' | 'end' | 'baseline'

SpacingKeyword

'none' | 'small' | 'base' | 'large'

MaybeTwoBoxEdgesShorthandProperty

T | `${T} ${T}`

MainAxisAlignment

'start' | 'center' | 'end' | 'space-between' | 'space-around' | 'space-evenly'

MaybeAllBoxEdgesShorthandProperty

T | `${T} ${T}` | `${T} ${T} ${T}` | `${T} ${T} ${T} ${T}`

Was this section helpful?

Laying out elements in a row

import React from 'react';

import {

render,

InlineStack,

} from '@shopify/ui-extensions-react/admin';

render('Playground', () => <App />);

function App() {

return (

<>Child 1</>

<>Child 2</>

<>Child 3</>

<>Child 4</>

</InlineStack>

);

}

Examples

Laying out elements in a row

React

import React from 'react';
import {
  render,
  InlineStack,
} from '@shopify/ui-extensions-react/admin';

render('Playground', () => <App />);

function App() {
  return (
    <InlineStack gap>
      <>Child 1</>
      <>Child 2</>
      <>Child 3</>
      <>Child 4</>
    </InlineStack>
  );
}

JS

import {extension, InlineStack} from '@shopify/ui-extensions/admin';

export default extension('Playground', (root) => {
  const inlineStack = root.createComponent(
    InlineStack,
    {
      gap: true,
    },
    [
      root.createText('Child 1'),
      root.createText('Child 2'),
      root.createText('Child 3'),
      root.createText('Child 4'),
    ],
  );

  root.appendChild(inlineStack);
});

Preview

Anchor to relatedRelated

BlockStack
